Maintenance 95
1208531 | 03.07.2012
3 Allow about 1/2 liter of fluid to drain.
First, the water which has collected on the bottom of the tank will run out.
4 Install the screw plug (1).
4.1 Secure the screw connections with Ergo 4207 and tighten by hand, not
with torque. Observe the table Torque: Drain cock / hydraulic tank,
Page 112
9.8.5 Fuel filter element
Fig. 9-8 Fuel filter
Replace fuel filter element (1) according to the maintenance plan.
9.8.6 Water separator filter element
Fig. 9-9 Water separator
Drain filter
housing
If the red float ring rises, the water must be drained from the housing at once.
1 Open drain cock (3).
2 Allow water to drain.
3 Close drain cock (3).
