Ammann ARX 45 - Specifications; Roller Designation; Identification Plate

22 ARX 4
1208531 | 03.07.2012
2.2.2 Specifications
Tab. 2-4 ARX 4 Performance Characteristics
Fill levels
Tab. 2-5 Fill levels ARX 4
2.3 Roller designation
2.3.1 Identification plate
An identification plate is affixed to the roller for identification. The identification plate
is attached to the rear part of the chassis below the steering column.
ARX 36 ARX 40 ARX 45 ARX 40 K ARX 45 K
Service weight according to CECE (kg) 3740 4125 4670 3840 4070
Max. service weight (kg) 4300 4700 5100 4700 5100
Static linear load (kg/cm) 14.4 15.8 16.9 15.8 16.9
Wheel load (kg) - - - 480 508
Inside turning radius (mm) 2581 2581 2621 2581 2621
Amplitude (mm) 0.57/0.36 0.57/0.36 0.55/0.34 0.57/0.36 0.55/0.34
Max. compaction force per roller drum (kN) 50 52 55 52 55
Gradient in % with/without vibration 30/40 30/40 30/40 30/40 30/40
Drive YANMAR 3TNV88/Euromot 3A - EPA Inter 4
Performance according to ISO 3046 30.0kW / 40.8HP
Operating speed 1.) 2100 1/min 2.) 2400 1/min
Travel speed 0-10km/h
Steering angle/pivoting +/-32°/+/-8°
Vibration frequency 2100/2400 1/min 1.) 45Hz 2.) 57Hz
Container Contents
Water tank capacity 350l
Hydraulic oil tank 37l
Diesel tank 59l
Anti-adhesive tank 18l
