Lmin = 5 m
2x min 2100 kg
(2x min 4650lb)
8400 kg
(18 600 lb)
Lmin = 5m
2x min 2100 kg
(2x min 4650 lb)
2.1. Major Safety Precautions
19. Sling points Sling the Machine in these points only. (Symbols located
on both sides of frames)
20. Sling points Sling the Machine in these points only. (symbols located
along both sides of the frame)
21. Supporting point Locate hand jack or xed support of the Machine here.
(symbol located on the front and rear frame along both
sides)
22. Lifting diagram Use rigging of sucient loading capacity to lift the Ma-
chine. Secure the Machine’s joint before lifting. (symbol
located on the left, on the front frame)
23. Hearing protectors If there is no cab on the machine or you are working with
the windows open, use hearing protectors (the symbol
located on the left side of the control panel).
24 . Danger zone. Keep a safe distance from the cutter and nal compaction
device, if in operation. (Symbol located on the front right
yoke – optional equipment)
25. Machine repair Do NOT start the engine! Hang the sign onto steering
wheel. The sign is supplied together with machine acces-
sories and should be kept in documentation locker.
