Releasing of the brakes of the machine:
Multi-purpose relieve valves are located on travel hydroelectric
generator. The travel hydroelectric generator is located on the
LH side, in engine compartment.
Remove hose (3) away from the clip.
Disconnect hose (1) in quick-coupler (2).
Connect hose (3) into quick-coupler (2).
Connect battery disconnector (51).
Before releasing the brakes, secure the
machine using wooden blocks against
accidental moving!
Turn the bonnet raising lever to the vertical position, see the
gure.
