Modbus
Address
Byte Name
Bit Identification
23
volts_average
Phase Voltage Average
(BCD format)
24
current_ave
Current Average
(0…250%)
25-29
Reserved
30
serial_high
Serial Number High
Top 16 bit of serial number
31
Serial_low
Serial Number Low
Lower 16 bit of serial number
32
mia_sw_ver
IPM Software Version –
where
x = Top 3 bits (Hardware Ver.)
y = Bot 5 bits (Software Ver.)
33
sub_second
Time Sub – Second
34
second
Time – Second
35
minute
Time – Minute
36
hour
Time – Hour
37
date
Date
eg. 1 = 1
st
, 15 = 15
th
38
month
Month
eg. 1 = Jan, 6 = Jun
39
year
Year (two digits only)
40
day
Day
eg. 0 = Sunday,
1 = Monday
41
pilot_mode
EC Pilot Mode
0 = Invalid Data
1 = RTM
2 = Diode
42
param_itm
ITM Module
0 = Invalid Data
1 = 415V
2 = 1000V
3 = None
43
param_mb_adr
Modbus Address
0 = Invalid Data
1……31
44
param_mb_bau
d
Modbus Baud Rate
0 = Invalid Data
1 = 1200 Even Parity
2 = 1200 Odd Parity
3 = 1200 No Parity
4 = 2400 Even Parity
5 = 2400 Odd Parity
6 = 2400 No Parity
7 = 4800 Even Parity
8 = 4800 Odd Parity
9 = 4800 No Parity
10 = 9600 Even Parity
11 = 9600 Odd Parity
12 = 9600 No Parity
13 = 19200 Even Parity
14 = 19200 Odd Parity
15 = 19200 No Parity
Modbus
Address
Byte Name
Bit Identification
45
machine_type
Machine Type
0 = - - - -
1 = J-bo - Jumbo
2 = Fan
3 = Drill
4 = Pump
5 = Hpmp - Hydraulic Pump
6 = Wpmp - Water Pump
7 = DCB
8 = Bolt - Bolter
9 = HRMr - Hard Rock Miner
10 = Belt
11 = Winc - Winch
12 = Crush - Crusher
13 = DPlug – Dummy Plug
14 = Spare
46
machine_num
Machine Number
0 = Invalid Data
1 …. 40
47
cur_range_para
m
FLC Setting (See OC
section)
1..32 = 5.125..10.000A
33..64 = 10.25..20.00A
65..96 = 20.5..40.0A
97..128 = 41..80A
129..160 = 82..160A
161..192 = 164..320A
193..224 = 328..640A
48
short_cct_para
m
SC Trip Level (xFLC)
0 = Invalid Data
1 = 3x
2 = 3.5x
3 = 4x
4 = 4.5x
5 = 5x
6 = 5.5x
7 = 6x
8 = 6.5x
9 = 7x
10 = 7.5x
11 = 8x
12 = 8.5x
13 = 9x
14 = 9.5x
15 = 10x
49
sc_trp_tm_para
m
SC Trip Time
0 = Invalid Data
1 = 20 ms
2 = 40 ms
3 = 60 ms
4 = 80 ms
5 = 100 ms
6 = 120 ms
7 = 160 ms
