Modbus
Address
Byte Name
Bit Identification
50
time_mul_para
m
O/L Trip Time @ 6x FLC
0 = Invalid Data
1 = 3s
2 = 4s
3 = 5s
4 = 6s
5 = 7s
6 = 8s
7 = 10s
8 = 12s
9 = 14s
10 = 16s
11 = 20s
12 = 24s
13 = 28s
14 = 32s
15 = 40s
51
cool_mul_para
m
S-Cool Ratio
0 = Invalid Data
1 = 1.0
2 = 1.5
3 = 2.0
4 = 2.5
5 = 3.0
6 = 4.0
7 = 5.0
52
ol_rst_param
O/L Reset Level
0 = Invalid Data
1 = 30%
2 = 40%
3 = 50%
4 = 60%
5 = 70%
6 = 80%
7 = 90%
8 = A-30%
9 = A-40%
10 = A-50%
11 = A-60%
12 = A-70%
13 = A-80%
14 = A-90%
53
cur_bal_param
Current Balance Trip
0 = Invalid Data
1 = 5%
2 = 10%
3 = 20%
4 = 50%
5 = OFF
54
p_und_cur
Under I Trip
0 = Invalid Data
1 = 32%
2 = 40%
3 = 48%
4 = 56%
5 = 64%
6 = 72%
7 = 80%
8 = 88%
9 = 96%
10 = OFF
Modbus
Address
Byte Name
Bit Identification
55
rc_lev_param
Ires Trip Level (%FLC)
0 = Invalid Data
1 = 10%
2 = 20%
3 = 30%
4 = 40%
5 = 50%
6 = 60%
7 = 80%
8 = 100%
9 = 120%
10 = 150%
11 = 200%
12 = 250%
13 = OFF
56
rc_tim_param
Ires Trip Time
0 = Invalid Data
1 = 100ms
2 = 200ms
3 = 500ms
4 = 1 Sec
5 = 2 Sec
6 = 3 Sec
7 = 5 Sec
57
el_sens
RCD Trip Level
0 = Invalid Data
1 = 25mA
2 = 50mA
3 = 100mA
4 = 200mA
5 = 500mA
6= OFF
58
el_time
RCD Trip Time
0 = Invalid Data
1 = Ins. (Instantaneous)
2 = 50ms
3 = 100ms
4 = 150ms
59
ectime_adj
Pilot Trip Time
0 = Invalid Data
1 = 80ms
2 = 120ms
3 = 160ms
4 = 200ms
5 = 300ms
6 = 400ms
7 = 500ms
60
remote_control
Remote Start
0 = Invalid Data
1 = No
2 = Yes
3 = Aux
61
pilot_latch
Pilot Latch
0 = Invalid Data
1 = On
2 = OFF
62
meg_level
Meg Level
0 = Invalid Data
1 = 1.0M
2 = 2.0M
3 = 5.0M
4 = 10M
5 = 20M
6 = None
