Modbus
Address
Byte Name
Bit Identification
63
uv_lev_param
Under Voltage Trip Level
0 = Invalid Data
1 = 40%
2 = 50%
3 = 60%
4 = 70%
5 = 75%
6 = 80%
7 = 85%
8 = 90%
9 = 95%
10 = OFF
64
b_emf_time
Back EMF Time
0 = Invalid Data
1 = 2 Sec
2 = 5 Sec
3 = 10 Sec
4 = 15 Sec
5 = 20 Sec
65
hc_alm_param
High Current Alarm
0 = Invalid Data
1 = 100%
2 = 108%
3 = 120%
4 = 140%
5 = 160%
6 = 200%
7 = 240%
8 = 280%
9 = 320%
10 = 360%
11 = 400%
12 = 500%
13 = 600%
14 = OFF
66
ta_alm_param
O/L Alarm Level
0 = Invalid Data
1 = 50%
2 = 60%
3 = 70%
4 = 75%
5 = 80%
6 = 85%
7 = 90%
8 = 95%
9 = OFF
67
uc_alm_param
Under Current Alarm
0 = Invalid Data
1 = 32%
2 = 40%
3 = 48%
4 = 56%
5 = 64%
6 = 72%
7 = 80%
8 = 88%
9 = 96%
10 = Off
Modbus
Address
Byte Name
Bit Identification
68
ec_alm_param
Earth Leakage Alarm
0 = Invalid Data
1 = 10%
2 = 20%
3 = 30%
4 = 40%
5 = 50%
6 = 60%
7 = 80%
8 = OFF
69
p_burp_num
Number of Burp Pulses
0 = Invalid Data
1 = None
2 = 1
3 = 2
4 = 3
5 = 4
6 = 5
7 = 6
70
p_burp_on
Burp On Time
0 = Invalid Data
1 = 0.6 S
2 = 0.8 S
3 = 1.0 S
4 = 1.2 S
5 = 1.5 S
6 = 2.0 S
7 = 2.5 S
8 = 3.0 S
71
p_burp_off
Burp Off Time
0 = Invalid Data
1 = 0.6 S
2 = 0.8 S
3 = 1.0 S
4 = 1.2 S
5 = 1.5 S
6 = 2.0 S
7 = 2.5 S
8 = 3.0 S
72
p_4_20_op
4-20mA Output
0 = Invalid Data
1 = O/L
2 = Iave
3 = lel
4 = MΩ
73-74
Reserved
75
_snoreIndex
Snore Delay
0 = Invalid Data
1 = OFF
2 = 5
3 = 10
4 = 15
5 = 20
6 = 8F
7 = 15F
8 = 20F
9 = 30F
10 = 60F
76
RCD_rst_lock
RCD Reset Lock
0 = Invalid Data
1 = OFF
2 = ON
77-78
Reserved
