Digital Video Recorder User Manual
60
8.1 Setting Motion Detection
Steps:
1. Enter Motion Detection interface of Camera Management and choose a camera you want to set up motion
detection.
Menu> Camera> Motion
2. Set detection area and sensitivity.
Check checkbox to enable motion detection, use the mouse to draw detection area(s) and drag the
sensitivity bar to set sensitivity.
Click to set alarm response actions.
Figure 8. 1 Set Detection Area and Sensitivity
3. Click Trigger Channel tab and select one or more channels which will start to record or become full-screen
monitoring when motion alarm is triggered.
Figure 8. 2 Set Trigger Camera of Motion Detection
4. Set arming schedule of the channel.
Select Arming Schedule tab to set the channel’s arming schedule.
Choose one day of a week and up to eight time periods can be set within each day. Or you can click the
Copy button to copy the time period settings to other day(s).
Time periods shall not be repeated or overlapped.
