Digital Video Recorder User Manual
78
Figure 10. 20 Network Traffic Interface
2. You can view the sending rate and receiving rate information on the interface. The traffic data is refreshed
every 1 second.
10.4 Configuring Network Detection
Purpose:
You can obtain network connecting status of DVR through the network detection function, including network delay,
packet loss, etc.
10.4.1Testing Network Delay and Packet Loss
Steps:
1. Enter the Network Traffic interface.
Menu > Maintenance > Net Detect
2. Click the Network Detection tab to enter the Network Detection menu.
Figure 10. 21 Network Detection Interface
3. Select a NIC to test network delay and packet loss.
4. Enter the destination address in the text field of Destination Address.
5. Click the Test button to start testing network delay and packet loss.
10.4.2Exporting Network Packet
Purpose:
By connecting the DVR to network, the captured network data packet can be exported to USB-flash disk, SATA
and other local backup devices.
Steps:
1. Enter the Network Traffic interface.
Menu > Maintenance > Net Detect
2. Click the Network Detection tab to enter the Network Detection interface.
3. Select the backup device from the dropdown list of Device Name.
Click the Refresh button if the connected local backup device cannot be displayed. When it fails to detect the
backup device, please check whether it is compatible with the DVR. You can format the backup device if the
format is incorrect.
Figure 10. 22 Export Network Packet
4. Click the Export button to start exporting.
