5-3 System Menu System Operations
5-4 PN: 10580-00252 Rev. J Site Master User Guide
System Options Menu
Key Sequence: Shift, System (8) > System Options
Date and Time: This key brings up a dialog box for setting the current date
and time. Use the submenu keys or the Left/Right arrow keys to select the
field to be modified. Use the keypad, the Up/Down arrow keys or the rotary
knob to select the date and time. Press Enter to accept the changes, or
press the Esc key to return to normal operation without changing anything.
Ethernet Config: Press this submenu key to display the Ethernet submenu
and to open the Ethernet Editor dialog box to set the IP address of the
instrument. For details refer to Chapter 7, “Ethernet Connectivity
(Option 411)”.
Language: This submenu key brings up a selection box allowing selection
from a list of built-in languages for the Spectrum Master displays. The
languages currently available are English, French, German, Spanish,
Japanese, Chinese, Korean, and Italian. In addition, up to two custom
languages may be loaded into the instrument if they have been defined using
the Master Software Tools. If a mode does not have language translations
available, English is the default language. Press Enter to accept the change,
or press the Esc key to return to normal operation without changing the
setting.
Display: The Display submenu key opens the “Display Settings Menu”
on page 5-6 allowing brightness control and the selection of the default color
display, black & white display, night vision display, or a high contrast display.
Name: Opens a dialog box to name the instrument. The unit can be named
using the keypad to select numbers and the touch screen keys to select letter
groups. Use the Shift key to select an upper case letter. Use the Left/Right
directional arrows to move the cursor position. The Back Space key will
remove the last character entered. Press Enter to save the name.
Volume: The current volume setting is displayed on the screen. Use the
keypad, the Up/Down arrow keys or the rotary knob to change the volume
and press the Enter key to accept the change.
Reset: Press this submenu key to open the “Reset Menu” on page 5-7.
More: Press this submenu key to open the “System Options 2/2 Menu”
on page 5-5.
Figure 5-3. System Options Menu
Reset
System Options
Date
&
Time
Language
Name
Volume
Ethernet
Config
More
Display
