Host Interface 11 (114)
3.2.1 Application Connector Pin Overview
Depending on operating mode, the pins have different names and different functionality.
Presented below is an overview of all pins except GND and 3V3.
The ASI (Anybus Safety Interface) signals are used by a safety module to connect to the safety
module interface of an Anybus CompactCom M40 series module.
Pin Signal Name Type Notes
Serial
Mode
SPI Mode 8-bit
Mode
16-bit
Mode
Shift
Register
Mode
49 DIP1_0 DIP1_0 A0 WEH DIP1_0 I
-
24 DIP1_1 DIP1_1 A1 A1 DIP1_1 I
-
48 DIP1_2 DIP1_2 A2 A2 DIP1_2 I
-
23 DIP1_3 DIP1_3 A3 A3 DIP1_3 I
-
47 DIP1_4 DIP1_4 A4 A4 DIP1_4 I
-
22 DIP1_5 DIP1_5 A5 A5 DIP1_5 I
-
46 DIP1_6 DIP1_6 A6 A6 DIP1_6 I
-
21 DIP1_7 DIP1_7 A7 A7 DIP1_7 I
-
45 SS A8 A8 LD I
-
20 SCLK A9 A9 SCLK O, I
-
44 MISO A10 A10 DO O, I
-
19 MOSI A11 A11 DI I
-
43 ASI RX A12 A12 I
-
18 ASI TX A13 A13 O, I
-
14 DIP2_0 DIP2_0 D0 D0 DIP2_0 I, I/O
-
39 DIP2_1 DIP2_1 D1 D1 DIP2_1 I, I/O
-
15 DIP2_2 DIP2_2 D2 D2 DIP2_2 I, I/O
-
40 DIP2_3 DIP2_3 D3 D3 DIP2_3 I, I/O
-
16 DIP2_4 DIP2_4 D4 D4 DIP2_4 I, I/O
-
41 DIP2_5 DIP2_5 D5 D5 DIP2_5 I, I/O
-
17 DIP2_6 DIP2_6 D6 D6 DIP2_6 I, I/O
-
42 DIP2_7 DIP2_7 D7 D7 DIP2_7 I, I/O
-
4 LED1B LED1B LED1B D8 LED1B O, I/O In modules supporting RMII,
these pins are used for the
RMII interface, see RMII
Reduced Media-Independent
Interface, p. 17.
29 LED1A LED1A LED1A D9 LED1A O, I/O
5 LED2B LED2B LED2B D10 LED2B O, I/O
30 LED2A LED2A LED2A D11 LED2A O, I/O
6 LED3B LED3B LED3B D12 LED3B OD, I/O
31 LED3A LED3A LED3A D13 LED3A OD, I/O
7 LED4B LED4B LED4B D14 LED4B O, I/O
32 LED4A LED4A LED4A D15 LED4A O, I/O
34 WE WEL CT I
-
33 OE OE I
-
10 CS CS I
-
9 IRQ IRQ IRQ PA O
-
28 RX ASI RX ASI RX ASI RX ASI RX I Connect to 3V3 if not used.
3 TX / OM3 ASI TX /
OM3
ASI TX /
OM3
ASI TX /
OM3
ASI TX /
OM3
O Strapping input with internal
weak pull-up during powerup.
To configure OM3, use an
external pull-up/pull-down of
1.0 to 2.2 kΩ). The pin
changes to output after
powerup.
36 OM0 OM0 OM0 OM0 OM0 I
-
11 OM1 OM1 OM1 OM1 OM1 I
-
Anybus
®
CompactCom
M40 Hardware Design Guide HMSI-216-126 EN 2.6
