Apogee Symphony Desktop User’s Guide

I/O Views

Input 1-2 Overview

The Input 1-2 Overview has 3 different presentations, based on the Preamp setting: SD-MP, AP-66

and AP-57.

1. Input Gain - tap to set the gain of the preamp

with the Control knob, when Analog Level is

set to Mic or Instrument. Gain Control is

hidden when Analog Level is set to +4dBu or

-10 dBV line input.

2. Digital meter - displays the digital level after

A/D conversion

3. Lo-Z Impedance - (AP-66 only) set the

impedance of the mic preamp to low (300

ohms) when using low impedance mics, such

as certain ribbon mics.

4. Output level - (AP-66, AP-57 only) tap to set

the output level of the mic preamp stage.

5. GL - Gain link - (AP-66, AP-57 only) link the

Input gain to the Output level so increasing

the Input gain reduces the Output level to

maintain a consistent signal level. This is

useful when driving the mic preamp emulation

into distortion.

6. -20 db Pad - (AP-57 only) decreases the

sensitivity of the analog input by 20 dB.

Engage the -20 dB pad when gain is set to 0

but the input is still overloading.
