Apollo Thunderbolt - Page 208

Apollo Thunderbolt Software Manual Device Drivers 208
Apollo 8p Default I/O (ADAT Mode)
Apollo 8p Driver Default I/O Table
Digital I/O Mode: ADAT
INPUTS OUTPUTS
1 MIC/LINE/Hi-Z 1 1 MON L
2 MIC/LINE/Hi-Z 2 2 MON R
3 MIC/LINE 3 3 LINE 1
4 MIC/LINE 4 4 LINE 2
5 MIC/LINE 5 5 LINE 3
6 MIC/LINE 6 6 LINE 4
7 MIC/LINE 7 7 LINE 5
8 MIC/LINE 8 8 LINE 6
9 ADAT 1 9 ADAT 1
10 ADAT 2 10 ADAT 2
11 ADAT 3 11 ADAT 3
12 ADAT 4 12 ADAT 4
13 ADAT 5 13 ADAT 5
14 ADAT 6 14 ADAT 6
15 ADAT 7 15 ADAT 7
16 ADAT 8 16 ADAT 8
17 VIRTUAL 1* 17 VIRTUAL 1*
18 VIRTUAL 2* 18 VIRTUAL 2*
19 VIRTUAL 3* 19 VIRTUAL 3*
20 VIRTUAL 4* 20 VIRTUAL 4*
21 VIRTUAL 5* 21 VIRTUAL 5*
22 VIRTUAL 6* 22 VIRTUAL 6*
23 VIRTUAL 7* 23 VIRTUAL 7*
24 VIRTUAL 8* 24 VIRTUAL 8*
25 MON L* † 25 CUE1 L
26 MON R* † 26 CUE1 R
27 AUX1 L* † 27 CUE2 L
28 AUX1 R* † 28 CUE2 R
29 AUX2 L* † 29 CUE3 L (N/A)
30 AUX2 R* † 30 CUE3 R (N/A)
31 CUE4 L (N/A)
32 CUE4 R (N/A)
* Software Outputs
(for DAW inputs)
*Software Inputs
(for Console inputs)
† In multi-unit setups, available on monitor unit only
