Apollo Thunderbolt Software Manual Device Drivers 209
Apollo 8p Default I/O (4x Rates, ADAT Mode)
Apollo 8p Driver Default I/O Table
4x Sample Rates, ADAT Mode
INPUTS OUTPUTS
1 MIC/LINE/Hi-Z 1 1 MON L
2 MIC/LINE/Hi-Z 2 2 MON R
3 MIC/LINE 3 3 LINE 1
4 MIC/LINE 4 4 LINE 2
5 MIC/LINE 5 5 LINE 3
6 MIC/LINE 6 6 LINE 4
7 MIC/LINE 7 7 LINE 5
8 MIC/LINE 8 8 LINE 6
9 ADAT 1 9 ADAT 1
10 ADAT 2 10 ADAT 2
11 ADAT 3 11 ADAT 3
12 ADAT 4 12 ADAT 4
13 ADAT 5 (N/A) 13 ADAT 5 (N/A)
14 ADAT 6 (N/A) 14 ADAT 6 (N/A)
15 ADAT 7 (N/A) 15 ADAT 7 (N/A)
16 ADAT 8 (N/A) 16 ADAT 8 (N/A)
17 VIRTUAL 1* (N/A) 17 VIRTUAL 1* (N/A)
18 VIRTUAL 2* (N/A) 18 VIRTUAL 2* (N/A)
19 VIRTUAL 3* (N/A) 19 VIRTUAL 3* (N/A)
20 VIRTUAL 4* (N/A) 20 VIRTUAL 4* (N/A)
21 VIRTUAL 5* (N/A) 21 VIRTUAL 5* (N/A)
22 VIRTUAL 6* (N/A) 22 VIRTUAL 6* (N/A)
23 VIRTUAL 7* (N/A) 23 VIRTUAL 7* (N/A)
24 VIRTUAL 8* (N/A) 24 VIRTUAL 8* (N/A)
25 MON L* † 25 CUE1 L
26 MON R* † 26 CUE1 R
27 AUX1 L* † 27 CUE2 L
28 AUX1 R* † 28 CUE2 R
29 AUX2 L* † (N/A) 29 CUE3 L (N/A)
30 AUX2 R* † (N/A) 30 CUE3 R (N/A)
31 CUE4 L (N/A)
32 CUE4 R (N/A)
*Software Outputs
(for DAW inputs)
*Software Inputs
(for Console inputs)
† In multi-unit setups, available on monitor unit only
