Apollo Thunderbolt Software Manual Device Drivers 210
Apollo 8p Default I/O (S/PDIF Mode)
Apollo 8p Driver Default I/O Table
Digital I/O Mode: S/PDIF
INPUTS OUTPUTS
1 MIC/LINE/Hi-Z 1 1 MON L
2 MIC/LINE/Hi-Z 2 2 MON R
3 MIC/LINE 3 3 LINE 1
4 MIC/LINE 4 4 LINE 2
5 MIC/LINE 5 5 LINE 3
6 MIC/LINE 6 6 LINE 4
7 MIC/LINE 7 7 LINE 5
8 MIC/LINE 8 8 LINE 6
9 S/PDIF L 9 S/PDIF L
10 S/PDIF R 10 S/PDIF R
11 VIRTUAL 1* 11 VIRTUAL 1*
12 VIRTUAL 2* 12 VIRTUAL 2*
13 VIRTUAL 3* 13 VIRTUAL 3*
14 VIRTUAL 4* 14 VIRTUAL 4*
15 VIRTUAL 5* 15 VIRTUAL 5*
16 VIRTUAL 6* 16 VIRTUAL 6*
17 VIRTUAL 7* 17 VIRTUAL 7*
18 VIRTUAL 8* 18 VIRTUAL 8*
19 MON L* † 19 CUE1 L
20 MON R* † 20 CUE1 R
21 AUX1 L* † 21 CUE2 L
22 AUX1 R* † 22 CUE2 R
23 AUX2 L* † 23 CUE3 L (N/A)
24 AUX2 R* † 24 CUE3 R (N/A)
25 CUE4 L (N/A)
26 CUE4 R (N/A)
* Software Outputs
(for DAW inputs)
*Software Inputs
(for Console inputs)
† In multi-unit setups, available on monitor unit only
Note: Apollo 8p recognizes S/PDIF digital I/O at sample rates up to 96 kHz.
