Apollo Thunderbolt Software Manual Device Drivers 211
Apollo 16, Apollo 16 MkII Default I/O
Apollo 16, Apollo 16 MkII Driver Default I/O Table
INPUTS OUTPUTS
1 LINE 1 1 MON L
2 LINE 2 2 MON R
3 LINE 3 3 LINE 1
4 LINE 4 4 LINE 2
5 LINE 5 5 LINE 3
6 LINE 6 6 LINE 4
7 LINE 7 7 LINE 5
8 LINE 8 8 LINE 6
9 LINE 9 9 LINE 7
10 LINE 10 10 LINE 8
11 LINE 11 11 LINE 9
12 LINE 12 12 LINE 10
13 LINE 13 13 LINE 11
14 LINE 14 14 LINE 12
15 LINE 15 15 LINE 13
16 LINE 16 16 LINE 14
17 AES/EBU L 17 LINE 15
18 AES/EBU R 18 LINE 16
19 VIRTUAL 1* 19 AES/EBU L
20 VIRTUAL 2* 20 AES/EBU R
21 VIRTUAL 3* 21 VIRTUAL 1*
22 VIRTUAL 4* 22 VIRTUAL 2*
23 VIRTUAL 5* 23 VIRTUAL 3*
24 VIRTUAL 6* 24 VIRTUAL 4*
25 VIRTUAL 7* 25 VIRTUAL 5*
26 VIRTUAL 8* 26 VIRTUAL 6*
27 MON L* † 27 VIRTUAL 7*
28 MON R* † 28 VIRTUAL 8*
29 AUX1 L* † 29 CUE1 L
30 AUX1 R* † 30 CUE1 R
31 AUX2 L* † 31 CUE2 L
32 AUX2 R* † 32 CUE2 R
33 CUE3 L (N/A)
34 CUE3 R (N/A)
35 CUE4 L (N/A)
36 CUE4 R (N/A)
*Software Outputs
(for DAW inputs)
*Software Inputs
(for Console inputs)
† In multi-unit setups, available on monitor unit only
