Argo-Hytos OPCom - Page 50

Subject to change · V 2.02.20 · EN
Page 50
www.argo-hytos.com
ldx SIdx name type Attr.
mapped on
PDO
default notes
1 PDO mapping for 1st
app obj. to be
mapped
unsigned 32 co 20000120h operating hours, 4 Byte
2 PDO mapping for 2nd
app obj. to be
mapped
unsigned 32 co 20030108h oil condition bits, 1 Byte
3 PDO mapping for 3rd
app obj. to be
mapped
unsigned 32 co 20030708h measurement bits,
1 Byte
4 PDO mapping for 4th
app obj. to be
mapped
unsigned 32 co 20030808h sensor status bits,
1 Byte
5 PDO mapping for 5th
app obj. to be
mapped
unsigned 32 co 20040008h temperature, 1 Byte
1A03h
TPDO4 mapping
parameter
record
0 Number of entries unsigned 8 ro 03h largest sub index
1 PDO mapping for 1st
app obj. to be
mapped
unsigned 32 co 20000220h timestamp of the
measurement, 4 Byte
2 PDO mapping for 2nd
app obj. to be
mapped
unsigned 32 co 20060108h NAS, 1 Byte in 2006h,
sub 01
3 PDO mapping for 3rd
app obj. to be
mapped
unsigned 32 co 20070108h GOST, 1 Byte in 2007h,
sub 01
2000h
time related
parameters of the
sensor
record
0 number of entries unsigned 8 ro 04h largest sub index
1 operating hours unsigned 32 ro y sensor up time in
seconds
2 timestamp of the last
measurement
unsigned 32 ro y timestamp of the last
measurement
3 laser operation hours
in hours
unsigned 32 ro laser operation hours
4 time to calibration
note S1 in hours
unsigned 32 ro time to calibration
note S1
2001h ISO measurement record
0 number of entries unsigned 8 ro 04h largest sub index
1 ISO4µm unsigned 8 ro y
2 ISO6µm unsigned 8 ro y
3 ISO14µm unsigned 8 ro y
4 ISO21µm unsigned 8 ro y
2002h SAE measurement record
0 number of entries unsigned 8 ro 04h largest sub index
1 SAE4µm unsigned 8 ro y offset of two to display
000, 00 and 0, valid for
all classes
0 == SAE 000
1 == SAE 00
2 == SAE 0
3 == SAE 1
…
14 == SAE 12
(maximum value)
