10
001-15698-EN rev.12
Hand Control2-function
See "Controls and Features" section on page 17 for additional details.
Wired Hand Controls
Infra-Red Hand Control
Icon Button Description 2-Function 4-Function Infra-Red
Up Button
Down Button
Right Button
Left button
Reclined Button * *
Sit Button * *
RTC (Return to Charge)
RTH (Return to Home) Button
Programming / Information Button (No Label)
* With Powered DPS Option
WARNING: Never let go of the hand control while the cord is extended as this could cause injuries to
others. When not used, put the hand control on the spreader bar.
NOTE: IR hand control comes with a wall bracket where it should be clipped after each use of the lift.
Two
Powered
Function
DPS
Function
Four
2-function
4-function
With Powered DPS
