How to Use the Exchanger
If the exchanger is already positioned in the
appropriate path, keep moving the lift through the
exchanger without stopping at the activation
station.
Changing the Path
If the exchanger is not already aligned in the
appropriate path proceed as described below.
Quick Release
Bring the lift to the activation station next to the exchanger.
Position the lift between the marks on the rail.
Once the exchanger detects the lift, it acknowledges with a
short beep and changes the path.
Wait until the exchanger has stopped completely then the lift
can be moved through the exchanger.
If the exchanger fails to operate automatically, or if there is an
emergency situation, engage the quick-release located
underneath the exchanger and slide the plate manually to
change the path completely.
WARNING: Be careful not to place your hand or fingers in
the path of the sliding plate to prevent pinching.
WARNING: Do not activate the quick release if the lift is in
the exchanger to prevent the unit from falling.
