Technical Data
PRODUCT INFORMATION Maxi Sky 2
Weight, complete (Four-function model)
12.3 kg (27 lb)
Weight, complete (Two-function model)
11.6 kg (26 lb)
Lifting capacity 120 kg (265 lb), 200 kg (440 lb), 272 kg (600 lb)
Strap length 2500 mm (98.4 in)
Lifting speed 5.1 cm/s (2.0 in/s) without load
4.2 cm/s (1.7 in/s) at 120 kg (265 lb)
3.8 cm/s (1.5 in/s) at 200 kg (440 lb)
3.3 cm/s (1.3 in/s) at 272 kg (600 lb)
Maximum stroke (from ceiling) 2300 mm (90.6 in)
Horizontal displacement speeds 10, 15 and 20 cm/s (4, 6 and 8 in/s)
Operating force of control < 5 N
ELECTRICAL
Duty cycle Up/Down Motor: Max 10%, 2 minute continuously
Left/Right Motor: Max 20%, 5 minutes continuously
Sit/Reclined Motor: Max 10%, 2 minutes continuously
Horizontal axis motor 24 VDC, 62 watts
Vertical axis motor 24 VDC, 360 watts for 2 minutes max.
Rating 24 VDC, 15 A max.
Noise level for either raising or
lowering, with or without load
61 dBA max. (with or without load)
Medical equipment
Type BF protection against electrical shock in accordance with IEC 60601-1
WARNING: Portable RF communications equipment (including peripherals such as antenna cables and
external antennas) should be used no closer than 30 cm to any part of the Maxi Sky 2, including cables
specified by the manufacturer. Otherwise, performance degradation of this equipment could result. See
"Electromagnetic Compatibility" section for more details.
Battery type 12 V, 5 Ah, sealed rechargeable valve regulated lead acid battery
Battery capacity Provides up to 120 transfers with a load of 100 kg (220 lb), up to 70
transfers with a load of 200 kg (440 lb)
Degree of protection - hand control IPX7
Degree of protection - Maxi Sky 2 IP24
Lift - protection class - shock prevention
Internally powered equipment
Battery charger input 100-240 VAC, 50-60 Hz, 57 - 70 VA.
Battery charger output 28.1 VDC, 1 A max, 28.1 VA
Battery Charger safety protection Class 2, double insulated
OPERATION, TRANSPORT AND STORAGE CONDITIONS
Normal Operation Ambient temperature range: 5°C to 40°C (41°F to 104°F)
Relative humidity range: 15% to 93%, non-condensing
Atmospheric pressure range: 700 hPa to 1060 hPa
Transport / Storage Ambient temperature range: -40°C to 70°C (-40°F to 158°F)
Relative humidity range: 0% to 93%, non-condensing
Atmospheric pressure range: 500 hPa to 1060 hPa
WARNING: This equipment is not suitable in the presence of flammable anesthetic mixtures with air or
oxygen, or with nitrous oxide.
