ARM Cortex-R4 - Page 160

Events and Performance Monitor
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 6-4
ID073015 Non-Confidential
[22] Instruction cache tag RAM parity or correctable ECC error. Yes 0x4A
[23] Instruction cache data RAM parity or correctable ECC error. Yes 0x4B
[24] Data cache tag or dirty RAM parity error or correctable ECC error. Yes 0x4C
[25] Data cache data RAM parity error or correctable ECC error Yes 0x4D
[26] TCM fatal ECC error reported from the prefetch unit. - 0x4E
[27] TCM fatal ECC error reported from the load/store unit. - 0x4F
N/A Store buffer merge. - 0x50
N/A LSU stall caused by full store buffer. - 0x51
N/A LSU stall caused by store queue full. - 0x52
N/A Integer divide instruction, SDIV or UDIV , executed. - 0x53
N/A Stall cycle caused by integer divide. - 0x54
N/A PLD instruction that initiates a linefill. - 0x55
N/A PLD instruction that did not initiate a linefill because of a resource shortage. - 0x56
N/A Non-cacheable access on AXI master bus. - 0x57
[28] Instruction cache access.
This is an analog to event 0x04 .
- 0x58
N/A Store buffer operation has detected that two slots have data in same cache line
but with different attributes.
- 0x59
[29] Dual issue case A (branch). - 0x5A
[30] Dual issue case B1, B2, F2 (load/store), F2D. - 0x5B
[31] Dual issue other case. - 0x5C
[32] Double precision floating point arithmetic or conversion instruction executed. - 0x5D
[33] Data cache data RAM fatal ECC error. - 0x60
[34] Data cache tag/dirty RAM fatal ECC error. - 0x61
[35]
Processor livelock because of hard errors or exception at exception vector.
a
- 0x62
[36] Unused. - 0x63
[37] ATCM multi-bit ECC error. - 0x64
[38] B0TCM multi-bit ECC error. - 0x65
[39] B1TCM multi-bit ECC error. - 0x66
[40] ATCM single-bit ECC error. - 0x67
[41] B0TCM single-bit ECC error. - 0x68
[42] B1TCM single-bit ECC error. - 0x69
Table 6-1 Event bus interface bit functions (continued)
EVNTBUS
bit position
Description
CFLR
update
Event
Ref.
Value
