12.5 Management registers
The Management registers define the standardized set of registers that all CoreSight
components implement. This section describes these registers.
Table 12-25 shows the contents of the Management registers for the processor debug unit.
12.5.1 Processor ID Registers
The Processor ID Registers are read-only registers that return the same values as the
corresponding CP15 MIDR and Feature ID Registers. See Chapter 4 System Control for
information about the information contained in these registers.
Table 12-26 shows the offset value, register number, mnemonic, and description that are
associated with each Processor Identification Register.
Table 12-25 Management registers
Offset
(hex)
Register
number
Access Mnemonic Description
0xD00-0xDFC 832-895 R - Processor Identification Registers.
See Processor ID Registers.
0xF00 960 RW ITCTRL Integration Mode Control Registers.
See Integration Mode Control Register on page 13-8.
0xFA0 1000 CLAIMSET Claim Tag Set Register.
See Claim Tag Set Register on page 12-36.
0xFA4 1001 CLAIMCLR Claim Tag Clear Register.
See Claim Tag Clear Register on page 12-37.
0xFB0 1004 W LOCKACCESS Lock Access Register.
See Lock Access Register on page 12-38.
0xFB4 1005 R LOCKSTATUS Lock Status Register.
See Lock Status Register on page 12-38.
0xFB8 1006 R AUTHSTATUS Authentication Status Register.
See Authentication Status Register on page 12-31.
0xFB8-0xFC4 1006-1009 R - Reserved.
0xFC8 1010 R DEVID Device Identifier. Reserved.
0xFCC 1011 R DEVTYPE Device Type Register.
See Device Type Register on page 12-38.
0xFD0-0xFFC 1012-1023 R - Identification Registers.
See Debug Identification Registers on page 12-39.
Table 12-26 Processor Identification Registers
Offset (hex) Register number Mnemonic Function
0xD00 832 MIDR Main ID Register
0xD04 833 CTR Cache Type Register
0xD08 834 TCMTR TCM Type Register
0xD0C 835 - Alias of MIDR
