Debug
ARM DDI 0363G Copyright © 2006-2011 ARM Limited. All rights reserved. 12-34
ID073015 Non-Confidential
Table 12-24 DBGPRSR Register bit assignments
Bits Name Function
[31:4] - Do not modify on writes. On reads, the value returns zero.
[3] Sticky reset status Sticky reset status bit. This bit is cleared on a read.
0 = the processor has not been reset since the last time this register was read.
1 = the processor has been reset since the last time this register was read. This is the reset value.
This sticky bit is set to 1 when nSYSPORESET is asserted.
[2] Reset status Reset status bit:
0 = the processor is not held in reset
1 = the processor is held in reset.
[1] Sticky power-down status Reserved. Always zero.
[0] Power-down status Reserved. Always one.
