FPU Programmers Model

ID073015 Non-Confidential

11.3 System registers

The VFPv3 architecture describes the following system registers:

• Floating-Point System ID Register on page 11-5

• Floating-Point Status and Control Register, FPSCR on page 11-6

• Floating-Point Exception Register, FPEXC on page 11-8

• Media and VFP Feature Registers, MVFR0 and MVFR1 on page 11-8.

Table 11-1 shows the VFP system registers in the Cortex-R4F FPU.

Note

The FPSID, MVFR0, and MVFR1 Registers are read-only. Attempts to write these registers are

ignored.

Table 11-2 shows that some of the VFP system registers can only be accessed in Privileged

modes.

Table 11-2 shows that a Privileged mode is sometimes required to access a VFP system register.

When a Privileged mode is required, an instruction that attempts to access a register in a

nonprivileged mode takes the Undefined Instruction exception.

For a VFP system register to be accessible, it must follow the rules in Table 11-2 and the VFP

must also be accessible according to the CPACR. See c1, Coprocessor Access Register on

page 4-46 for more information.

Table 11-1 VFP system registers

Floating-Point System ID Register, FPSID b0000 Read-only

0x4102314x

Floating-Point Status and Control Register, FPSCR b0001 Read/write

0x00000000

Floating-Point Exception Register, FPEXC b1000 Read/write

0x00000000

VFP Feature Register 0, MVFR0 b0111 Read-only

0x10110221

VFP Feature Register 1, MVFR1 b0110 Read-only

0x00000011

a. Bits [3:0] of the FPSID depend on the product revision. See the FPSID register description for more information.

Table 11-2 Accessing VFP system registers

Privileged access User access

FPEXC EN=0 FPEXC EN=1 FPEXC EN=0 FPEXC EN=1

FPSID Permitted Permitted Not permitted Not permitted

FPSCR Not permitted Permitted Not permitted Permitted

MVFR0, MVFR1 Permitted Permitted Not permitted Not permitted

FPEXC Permitted Permitted Not permitted Not permitted
