12.4.16 Operating System Lock Status Register
The DBGOSLSR contains status information about the locked debug registers.
Figure 12-12 on page 12-31 shows the DBGOSLSR bit assignments.
[12:5] Byte
address
select
The DBGDSWVR is programmed with word-aligned address. You can use this field to program
the watchpoint so it only hits if certain byte addresses are accessed:
b00000000 The watchpoint never hits.
bxxxxxxx1 The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFFC
)
+0 is accessed.
bxxxxxx1x The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFFC
)
+1 is accessed.
bxxxxx1xx The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFFC
)
+2 is accessed.
bxxxx1xxx The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFFC
)
+3 is accessed.
bxxx1xxxx The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFF8
)
+4 is accessed.
bxx1xxxxx The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFF8
)
+5 is accessed.
bx1xxxxxx The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFF8
)
+6 is accessed.
b1xxxxxxx The watchpoint hits if the byte at address (DBGDSWVR[31:0] &
0xFFFFFFF8
)
+7 is accessed.
[4:3] L/S Load/store access. The watchpoint can be conditioned to the type of access:
b00 = Reserved
b01 = load, load exclusive, or swap
b10 = store, store exclusive or swap
b11 = either.
A
SWP
or
SWPB
triggers on load, store, or either. A load exclusive instruction triggers on load or
either. A store exclusive instruction triggers on store or either, whether it succeeds or not.
[2:1] S Privileged access control. The watchpoint can be conditioned to the privilege of the access:
b00 = reserved
b01 = Privileged, match if the processor does a privileged access to memory
b10 = User, match only on non-privileged accesses
b11 = either, match all accesses.
For all cases, the match refers to the privilege of the access, not the mode of the processor.
[0] W Watchpoint enable:
0 = Watchpoint disabled. This is the reset value.
1 = Watchpoint enabled.
