Cycle Timings and Interlock Behavior

ID073015 Non-Confidential

First address not 64-bit aligned

VLDM{mode}.32 <Rn>{!}, {s1}

11 11 -

VLDM{mode}.32 <Rn>{!}, {s1,s2}

2 2 1,2 2 -

VLDM{mode}.32 <Rn>{!}, {s1-s3}

2 3 1,2,2 3 -

VLDM{mode}.32 <Rn>{!}, {s1-s4}

3 3 1,2,2,3 3 -

VLDM{mode}.64 <Rn>{!}, {d1}

22 22 -

VLDM{mode}.64 <Rn>{!}, {d1,d2}

3 3 2,3 3 -

VLDM{mode}.64 <Rn>{!}, {d1-d3}

4 4 2,3,4 4 -

VLDM{mode}.64 <Rn>{!}, {d1-d4}

5 5 2,3,4,5 5 -

Table C-25 Floating-point load/store instructions cycle timing behavior (continued)

Example instruction

Cycles/

memory

cycles

Cycles with

writeback (!)

Result

latency

(load)

Result

latency

(base

<Rn>)

Comments
