Arris NC4000 - Page 78

Table 4
RF Amplifier Tray Options
H3
OA4324HG fiber deep ultra-high output RF module, 60 dBmV, 1 GHz platform
S2
OA4244SG scalable high output RF module, 53dBmV, 1 Ghz platform
S3
OA4344SG scalable ultra-high output RF module, 60 dBmV, 1 GHz platform
Table 5
Level and Slope Options
A
1.0 GHz Applications
+53 dBmV output at 1002 MHz, 14 dB linear slope
H
1.0 GHz Applications
+60 dBmV output at 1002 MHz, 18 dB linear slope
Note: Contact ARRIS sales or field services for alternate output and slope configurations.
Table 6
Segmentation Options
Port 1
Port 3
Port 4
Port 6
1
Single combined return segment
(OA4444 module only)
TXA-1
TXA-1
TXA-1
TXA-1
RS4001-00
2
Two return segments to two transceivers
(ports 1+3 and ports 4+6)
TXF-1
TXF-1
TXA-1
TXA-1
RS4011-00
3
Three return segments
(ports 1+3, port 4, port 6)
TXF-1
TXF-1
TXA-2
TXA-1
RS4012-00
4
Four return segments
TXF-2
TXF-1
TXA-2
TXA-1
RS4022-00
5
Two return segmentsto a dual-channel
transceiver (ports 1+3 and ports 4+6)
TXA-2
TXA-2
TXA-1
TXA-1
RS4002-00
6
Single combined return segment with
redundant transceiver
TXA-1
and
TXF-
1
TXA-1
and
TXF-
1
TXA-1
and
TXF-
1
TXA-1
and
TXF-
1
RS4211-00
7
Two return segments to two redundant
dual channeltransceivers
TXA-2
and
TXF-
1
TXA-2
and
TXF-
1
TXA-1
and
TXF-
2
TXA-1
and
TXF-
2
RS4022-00
9
Return path configured on RF module
TXF-2
TXF-1
TXA-2
TXA-1
RS4000-00
Note: All segmentation options for OA4324HG RF modules require option 9
TM 87-10923 Rev E NC4000 Node Model Numbers B-3
Table 3
Forward Receiver Options
1
Single forward optical receiver
5
Two redundant forward optical receivers
A1
AR4x14 forward analog receiver
B1
Single AR4x24 forward optical receiver
B2
AR4x24 for two forward segments
B3
Three segmented AR4x24 forward optical receivers
B4
Four segmented AR4x24 forward optical receivers
B5
Two redundant AR4x24 forward optical receivers with FS4121
B6
Four redundant AR4x24 forward optical receivers to two RF segments with FS4121 for each
segment
B
