ASIX AX99100 User Manual

42
Copyright © 2016 ASIX Electronics Corporation. All rights reserved.
AX99100
PCIe to Multi I/O Controller
27:24
CS1n space Range
Local Address Space 1 Range for CS1n
CS1n Space Range = 2
(LCS1RAN + 1)
Hardware Default Value: 0xF
31:28
Reserved
Local Address Space 1 Address Setting (0x33~0x30)
Bit
Description
15:0
Local Address Space 1 address shift Base
Hardware Default Value: 0x0000
31:16
CS1n space Starting Address
Starting Address Shift of CS1n for Local Address Space 0
Hardware Default Value: 0x0000
Offset 0x53~0x7F:
Please reference section 3.3.1.
