10
ASSA ABLOY Hospitality
66 8003 016-3
3. To install the Orion EMS devices
3.1 To install a thermostat
mportant: This thermostat directly controls high voltage circuits
and must be installed by a licensed electrician.
mportant: All local codes must be followed when installing this thermostat.
The thermostat will control a variety of HVAC systems and the installation will
vary based on the type of system to which it is installed.
Figure 2
The master controller of the in-room system is the thermostat, shown in Figure 2.
To the guest, this device appears and operates as a standard digital thermostat;
however, this device also receives entry and exit information from the door lock
or switch as well as motion detected information from the motion sensor. This
information is used to determine the occupancy status of the room and implement
energy savings strategy based on this information. The guest operates the
thermostat, which communicates directly with the Visionline software/Orion EMS
software and the devices within the room.
