26
ASSA ABLOY Hospitality
66 8003 016-3
4. To set up a thermostat profile
Each thermostat which is set up in the Thermostats list of the Visionline software
(see Daily use manual Orion high voltage thermostat for details about that list) must
belong to a thermostat profile, e.g. a template with certain thermostat parameters.
When a thermostat is first set up, it must be initialized with the thermostat profile
parameters via the Initialize alternative in Orion Service; see Quick reference guide
Orion Service for details.
Note:
If one or more parameters of a thermostat profile are at a later occasion
updated, these new parameters are automatically sent to all concerned online
thermostats. If the thermostats are not online, they must be updated via the
Initialize alternative in Orion Service.
1. Double click on Thermostat profiles under the Lists tab in the Visionline
navigation window.
2. Click Add to add a new thermostat profile, or mark an existing profile and click
Properties.
3. Go through the different alternatives in the left pane of the Thermostat profile
details dialog; see details in sections 4.1-4.7.
4. When all settings have been made, click Save and Close (or Update and Close
if an existing profile was modified).
4.1 General
1. Enter Name and,
if desired, Description.
Figure 27
