35
ASSA ABLOY Hospitality
66 8003 016-3
2. Max fan cool is the maximum setting that the customer can make via the
thermostat. Choose between
low
mid
high; default
Note:
The ability to control fan speeds depends on the capability of the air handler
as some systems do not have three fan speeds.
3. Max fan heat is the maximum setting that the customer can make via the
thermostat. Choose between
low
mid
high; default
Note:
The ability to control fan speeds depends on the capability of the air handler
as some systems do not have three fan speeds.
4. If applicable, mark the checkbox 'Fan on when satisfied'. This is applicable if the
background sounds in the room should for guest comfort reasons not change.
Note:
The 'Fan on when satisfied' function will only apply to an occupied room.
5. At Cool down, duration (Fan time) and Fan speed of the fan during cool down
period can be chosen. It can also be chosen whether cool down should apply only
when in cool or only when in heat (mark the applicable checkbox).
Fan time; default is 2 minutes, can be in the range 1-10 minutes
Fan speed; default is 'Low', can be low, mid or high.
4.4 Limits
Note: For more information about 'unoccupied' and 'unsold', see section Basic EMS
logic in Daily use manual Orion high voltage thermostat.
1. At Setback type, choose
static; default (the static
setback temperatures
are configured in the
system and do not
change based on the
guest settings)
dynamic (the dynamic
setback temperatures
are configured as a set
number of degrees
above or below the
guest setting)
Figure 39
