Assa Abloy Orion Installation Manual

50
ASSA ABLOY Hospitality
66 8003 016-3
Appendix A: Quick reference of technical data
Dimensions (WxHxD) 112 x 117 x 35 mm (4 13/32" x 4 19/32" x 1 3/8")
Mains voltage input Universal voltage input 100VAC-277VAC; 50/60 Hz;
rated impulse voltage 4kV
Switch input Door switch - 1 exterior/1 interior
Multifunction input Motion sensor/card switch/pipe temp sensor
High voltage outputs - G1 (Fan 1): Type 1.B action. Max load 3A (3FLA/18LRA)
- G2 (Fan 2): Type 1.B action. Max load 3A (3FLA/18LRA)
- G3 (Fan 3): Type 1.B action. Max load 3A (3FLA/18LRA)
- RV (reversing valve): Type 1 action. Max load 0.5A
- Y (cooling/compressor): Type 1 action. Max load 0.5A
- W (heating): Type 1 action. Max load 0.5A
Low voltage outputs - Proportional 0-10V; heating
- Proportional 0-10V; cooling
- Switch output (max 24V AC/DC, SELV, max 0.1A)
Temperature sensor Integrated in thermostat
Temperature display Configurable: room temperature (default) or guest setting
Temperature display range 2-digit display
Adjustable setpoint temperature
range
17°C -32°C / 62°F - 90°F
Environment Normal indoor environment - Pollution degree 2
Operating temperature range 0°C -55°C / 32°F - 130°F
Service device Orion Service software and
service cable RJ12 to 3.5mm stereo jack
Radio (RF) signals ZigBee 2006
Lock to thermostat:
Door open - staff card
Door open - guest card
Door open from inside
Door closed
Deadbolt thrown/released
Thermostat to lock:
Room occupied
Motion sensor to thermostat:
Motion detected
Battery status
T hermostat to motion sensor:
Turn off when the room is occupied and door is closed
Turn on when the door is opened again
Thermostat deadband Configurable 1-3°F; default is 2°F
Heat/cool switching deadband Configurable 2-4°F; default is 3°F
Freeze guard 39°F / 4°C
Refresh cycle Optional
Humidity Optional
Intelligent switch Configurable: Disabled/use RV output/use G2 output;
default is disabled
Room not occupied timer Configurable 1-120 minutes; default is 8 minutes
Room not sold timer Configurable 12-24 hours; default is 16 hours
Table continued on next page
