60
ASSA ABLOY Hospitality
66 8003 016-3
To set up the online network
The online network for the example in Figure C10 looks as in Figure C12. The two
thermostats 102 and 103 must be set up under the same parent in the network,
i.e. be set up in the same PAN (personal area network). To set up the network,
follow the steps below:
1. Open SysMon (System Monitor) which is used for managing the online network;
double click on SysMon.exe in the Visionline installation folder.
2. Log on to SysMon; go to File/Log on and enter user ID and password. At
'Operator card', choose the applicable card encoder and click Enter.
3. Go to View/Online Network to show the Online Network tree.
4. Install the gateway; see User manual Online option for details.
5. Initialize thermostat 102 with 'normal parameters', i.e. all parameters except for
those related to suite. To do this, use the Initialize alternative in Orion Service
but leave the Suite settings empty. See Daily use manual Orion EMS for details
about Initialize.
6. Connect thermostat 102 to the gateway; see chapter 5
for details.
7. Connect motion sensor 102 to thermostat 102; see chapter 5
for details.
8. Connect lock 102 to thermostat 102; see chapter 5
for details.
9. Repeat steps 5-8 for the devices in room 103.
10.Initialize thermostat 102 with suite settings; click here
for details.
11.Read out the thermostat status for thermostat 102; click here
for details.
12.Read out the thermostat status for thermostat 103; click here
for details.
13.See the final Online Network tree in Figure C16
.
Figure C12
