24
ASSA ABLOY Hospitality
66 8003 016-3
3.2 To install an RF door switch
If VingCard online locks are not applicable at the installation, an RF door switch can
instead be used for monitoring the position of the door. The door switch is powered
by 2 AA batteries and the kit also includes a magnet (see Figure 25
) and two screws.
The door switch can be mounted as it is or on a wall-mounted casing (see Figure 26
)
which is purchased separately.
Note:
For best operation, the magnet should be installed maximum 10 mm (25/6'')
from the reed switch which is located as in Figure 24
.
Note:
It is also possible to use a wired door switch without radio; click here for
details.
3.2.1 RF door switch dimensions
Figure 24
