Assa Abloy Orion Installation Manual

56
ASSA ABLOY Hospitality
66 8003 016-3
click here
for details.
13.See the final Online Network tree in Figure C9
.
Figure C3
To initialize the master thermostat with suite settings
1. Choose Initialize in the left pane
of the Orion Service window.
2. Connect the service cable to the
thermostat in room 102.
3. Click the plus sign for the applicable
door area (in this example 'Floor 1')
and mark the master room, in this
example 102.
Figure C4
4. At Suite settings:
- Enter the Suite room (slave
room); in this example it is 103.
- Leave the Share occupancy
checkbox empty; this is only
applicable when there is just one
door to the entire suite;
click here
for more information
about that configuration.
Figure C5
5. Click the Initialize button.
Note:
It is only the master room
that is initialized with suite settings,
so steps 1-4 above are never
performed for the slave room.
Figure C6
