11
ASSA ABLOY Hospitality
66 8003 016-3
3.1.1 Step-by-step procedure
For a new thermostat, the following steps must be followed:
Figure 3: Service cable RJ12 to 3.5mm
stereo jack (Art. No 205 999 008)
Figure 4
1. Make sure that the thermostat has got the
latest available firmware:
- Plug the service cable (see Figure 3) into
the thermostat.
- In Orion Service (see Figure 4): choose
the Versions alternative and click the
Readout button. See Quick reference guide
Orion Service for more information about
the software.
2. Mount the thermostat according to here
.
3. Add the thermostat to the Thermostats list in
Visionline; in the Thermostat details dialog
you should also choose the profile to which
the thermostat should belong. If no applicable
thermostat profile exists in Visionline, create
one according to chapter 4
.
4. Initialize the thermostat with room number
and also with parameters according to the
chosen thermostat profile; follow the Initialize
section in Quick reference guide Orion Service.
Note:
If one or more parameters of a
thermostat profile are at a later occasion
updated, these new parameters will
automatically be sent to all concerned online
thermostats. If the thermostats are not online,
they are updated via the Initialize alternative
in Orion Service.
5. Make external connections according to here
.
6. If the thermostat should be online, set it up in
the online network according to the chapter To
commission the s
stem.
