Associated Research OMNIA II 8207 User Manual

26
AC SOURCE 500VA
OUTPUT
Power
630VA and 500W Maximum
Voltage
0 - 150.0V / 0 - 277.0V
Current
4.20A maximum for 0-150V range / 2.10A maximum 0-
277V range
Distortion
≤ 1% at 45-500Hz and output voltage within the 80~140Vac
at Low Range or the 160~277Vac at High Range.
(Resistive Load)
Regulation
≤ 0.5% + 5V (Resistive Load), From no load to full load
and Low Line to High Line (combined regulation)
Crest Factor
> 3
Test timing limit
< 350mS at start and between steps when internal AC
source is ON
SETTINGS
Voltage
Low range
0.0 - 150.0V
0.1
± (1.5% of setting +
2 counts)
High range
0.0 - 277.0V
Frequency
45.0Hz - 99.9Hz
0.1
±0.1% of setting
100Hz - 500Hz
1
A-Hi-limit
Range
4.20A/2.10A
Resolution
0.01
Accuracy
± (2 % of reading +2 counts)
OC Fold Current
Range
4.20A/2.10A
Resolution
0.01
Accuracy
± (2 % of reading +2 counts)
Response time
< 1500ms
MEASUREMENT
Voltage
0.0-277.0
0.1
± (1.5 % of reading
+2 counts)
Current
0.00-16.00
0.01
± (2 % of reading
+2 counts)
Power
0-4500
1
± (5% of reading +3
counts) for
PF>0.100
Power Factor
0.000-1.000
0.001
± (8 % of reading +5
counts)
Frequency
45-500Hz
0.1
±0.1Hz
GENERAL
Over Current Fold back
On/Off, When the output current exceeds the A-Hi value it
will fold back output voltage to keep constant output current
at A-Hi value.
Protection
OCP, OTP, OVP, OPP and Alarm
