Associated Research OMNIA II 8207 User Manual

64
TEST TYPE
PARAMETER
VALUE
Setup Sys.
PLC Remote
OFF
Address (GPIB only)
Measurement
Language
8
True RMS
English
Volume
Step Name
Color Style
5
OFF
Arctic
Smart GFI
0.4mA
Security
User ID
Password
Admin
8000
Security
OFF
MODELS 82X6 AND 82X7
Run Test
Voltage-HI
100.0V
Voltage-LO
0.0V
Amp-HI
10.00A
Amp-LO
0.00A
Dwell Time
1.0s
Delay Time
0.1s
Leakage-HI
10.00mA
Leakage-LO
0.00mA
Power-HI
1000W
Power-LO
0W
PF-HI
1.000
PF-LO
Active Link
0.000
OFF
MODEL 82X6 AND 82X7
LCT
Leakage-HI
3000A
Leakage-LO
0.0A
Voltage-HI
100.0V
Voltage-LO
Dwell Time
0.0V
1.0s
Delay Time
Offset
Leakage
Active Link
1.0s
0.0uA
RMS
OFF
Reverse
OFF
Neutral
CLOSED
Ground
CLOSED
Meas. Device
UL544NP
Probe
AC/DC
Ranging Mode
Ground to Line
AC+DC
Auto
Scanner
OOOOOOOOOOOOOOOO
NOTE: Scanner setup depends upon the Continuity Scanner setting. See
section 4.2.4 Hardware for more details on the Continuity Scanner setting.
