Rubber Track Loader
3. Systems Diagrams
3-5
Drive Loop System
The drive loop system (Figure 3-3) contains the following major components.
• Tandem pump
• Drive motors
• Pilot control manifold
• Drive control joysticks
Figure 3-5
Drive Loop System
