ASV RC-50 Service & Repair Manual

Rubber Track Loader
10. Transmission and Drive Disassembly and Assembly
10-6
Pump Drive Coupler Installation
Figure 10-15 10-012
1. Slide the pump drive coupler all the way onto the
tandem pump drive shaft.
Figure 10-16 10-011
2. Tighten the locking screw that secures the pump
drive coupler to the tandem pump drive shaft.
3. Install the tandem pump. Refer to Chapter 10.
Tandem Pump Installation.
4. Install the auxiliary gear pump. Refer to Chapter
10. Auxiliary Gear Pump Installation.
5. Install the seat. Refer to Chapter 6. Seat
Installation.
6. Add fuel and manufacturer-approved hydraulic
fluid.
Tandem Pump
Drive Shaft
Pump
Drive
Coupler
Tighten
Locking
Screw
Pump
Drive
Coupler
Tandem
Pum
p
