Page #80 background imageLoading...
Page #80 background image
- 80 -
10 Technical specifications of the light tower
10.1 Technical specifications of the engine/alternator/unit
50 Hz (230V - 1ph) 60 Hz (120V - 1ph)
Reference conditions 1) Rated frequency 50 Hz 60 Hz
Rated speed 1500 rpm 1800 rpm
Generator service duty PRP PRP
Absolute air inlet pressure 1 bar(a) 1 bar(a)
Relative air humidity 30% 30%
Air inlet temperature 25°C 25°C
Limitations 2) 7) Maximum ambient temperature 40°C 40°C
Altitude capability 3000 m 3000 m
Maximum relative air humidity 80% 80%
Minimum starting temperature Pending Test Pending Test
Minimum starting temperature, with coldstart equipment Pending Test Pending Test
Performance data 2) 3) 4)
5) Rated active power (PRP) 2.58 kW 2.85 kW
Rated apparent power (PRP) 2.58 kVA 2.85 kVA
Rated voltage line to line voltage 230 V 120 V
Rated current 11.21 A 23.75 A
Performance class (acc. ISO 8528-5:2005) G1 G1
Single step load acceptance 100% 100%
2.58 kW 2.85 kW
Fuel consumption at 0% load 0.32 kg/h 0.35 kg/h
Fuel consumption at 50% load 0.64 kg/h 0.69 kg/h
Fuel consumption at 75% load 0.85 kg/h 0.9 kg/h
Fuel consumption at 100% load 1.16 kg/h 0.97 kg/h
Specific fuel consumption 0.450 kg/kWh 0.475 kg/kWh
Fuel autonomy at full load with standard tank 97.12 h 116.14 h
Maximum sound power level (Lw) complies with 2000/14/EC 82 dB(A) 85 dB(A)
Capacity of standard fuel tank 120 l 120 l
