- 97 -
A3 Actuator Controller
C1 Capacitor (alternator)
F1-F2 Fuses 2A
G3 Alternator
K101-K104 Light control relay
K120 Mains relay
M7 Autotilt actuator
M10 Pump
Q1 Earth leakage 25A/30mA
Q2 Circuit breaker 6A
Q3 Circuit breaker 6A
Q4 Circuit breaker 6A
Q5 Circuit breaker 6A
Q6 Circuit breaker 10A
Q7 Circuit Breaker 2A, 2P
S10 GENSET/OFF/MAINS switch
S30 Autotilt switch up/down
S60 Earth leakage test button
T1 Current transformer
U1 Battery charger
V1-V4 Floodlight
W10 Spiral cable
X1 Outlet socket
X2 Inlet socket 16A
X3 Earth leakage test socket
X8 AC terminals
X10 Connector wire harness
X11 Auxiliary terminals
X16 Connector lighting
X17 Lighting terminals
X21-X24 Connector 2P+PE - Floodlights
X31-X35 Connector 2P - Diming
(02) Optional Power output connections
(03) Optional Mains connection
(07) Optional Autotilt
(12) Earth Leakage test socket
