ABLEPick pick-to-light communication protocol
20
4. ABLEPick TCP/IP communication Protocol
4.1 Communication Control Block (CCB) format
Communication data format (CCB: Communication Control Block) between PC and TCP/IP
controller is as below:
CCB LEN (L) =
Block length
CCB LEN (H) =
(8 Bytes + DATA Length)
MESSAGE TYPE = 60H
60H : port 1 , ( 61H : port 2)
Reserved
Reserved
Reserved
SUB-COMMAND
Description as below
SUB-NODE = {01H ~ C8H}
Specify tag address
(up to 200), 0FC:broadcasting
DATA
Command message
PS : For AT500 ,TCP/IP controller, only port 1 is available. So Message Type will
be always = 60H.
4.2 Sub-command List
Sub-command
Data
Direction
PC√TCP/IP
controller
Description
00H

Showing alphanumeric on tag (note ←)
01H

Turning off all alphanumeric on tag/clear all display in buffer
02H

LED indicator ON
03H

LED indicator OFF
04H

Buzzer ON
05H

Buzzer OFF
06H

Returning confirmation message from push-button
07H

Return shortage message from push-button
08H

Setting maximal field device address
09H

Reading status of the connected field devices
09H

Returning status of the connected field devices
0AH

Field device timeout
0BH

Query device malfunction
0BH

Returning device malfunction
0CH

Device being unable to execute the command
0DH

Returning Buttons locked message
(only active after sending message from the host to device)
FCH

Device resetting OK
0FH

Returning quantity under stock mode
10H

Flashing alphanumeric on tag
11H

Flashing LED (Lamp) indicator
12H

Setting flash timer
13H

Showing tag address
14H

Resetting device
15H

Disabling shortage push-button
16H

Enabling shortage push-button
17H

Emulating confirmation push-button
