Atop ABLEPick AT500 - 4.5.1 Protocol for AT50 C;AT70 C

ABLEPick pick-to-light communication protocol
42
05H
AT503A / AT502V / AT506-3W-123 / AT506-2W-24 /
AT506-2W-33A / AT504-2W-22A / AT50A-3W-523
06H
AT503-4K
Data[1] : F/W version
Data[2] : tag’s mode code, default = 73H
Data[3] : the configuration result of data[1], defined in sub-command = 1FH, data[0]=0AH,
please refer the page32 of 4.3.20.7 Configure Special function
Data[4] : delay time : such as 02H means “delay time” = 2 *0.4 sec = 0.8 sec
For example : Product ID code = 04H, AT530
Data[1] : F/W version
Data[2] : buffer size, default = 32H(50bytes)
Data[3] : block interval time : 0AH (10 msec)
Data[4] : 08H (default)
AT7XX
Data[0] : Product ID code
02H
AT505 / AT502 / AT50N / AT506 / AT511 / AT510 /
AT510M /AT705/AT703/AT702/AT70N/AT706/AT710M
AT506-2W-33
03H
AT50C/AT70C
04H
AT530/AT730
05H
AT503A / AT502V / AT506-3W-123 / AT506-2W-24 /
AT506-2W-33A / AT504-2W-22A / AT50A-3W-523
06H
AT503-4K
Data[1] : F/W version
Data[2] : tag’s mode code, default = 73H
Data[3] : the configuration result of data[1], defined in sub-command = 1FH, data[0]=0AH,
please refer the page32 of 4.3.20.7 Configure Special function
Data[4] : delay time : such as 02H means “delay time” = 2 *0.4 sec = 0.8 sec
Data[5] : LED color status
Data[6] :reserved (default = 02H)
For example : Product ID code = 02H, AT705
Data[1] : F/W version
Data[2] : tag mode = 73H
Data[3] : 02H (default)
Data[4] : 08H(default)
Data[5] : 00H(RED color)
Data[6] : 02H(reserved)
4.5 Specific protocol for some light models
4.5.1 Protocol for AT50C/AT70C
The CCB(communication Control Block ) from Host PC to AT50C/AT70C is as below :
CCB Description
CCB LEN(L)= 15H
Length of CCB in byte
CCB LEN(H) = 0x00
MESSAGE TYPE = 60H
60H: port1 of controller,
Reserved
