Atop ABLEPick AT500 - 4.3.20 Set Tags specific configuration; 4.3.20.1 Configure the LED lights color

ABLEPick pick-to-light communication protocol
28
adjusted by pressing up-count or down-count button to allow user to change quantity
SUB-COMMAND = 1EH
CCB LEN (L) = 09H
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1E H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = high byte value of timer
DATA[0] = Setting the number of digit is valid to adjust quantity: (Range: 01H ~ 06H)
01H: Only the 1
st
digit from right side on LED display is valid for adjusting
02H: Only 1
st
, 2
nd
digits from right side on LED display is valid for adjusting
:
06H: 1
st
to 6
th
digits are valid for adjusting
4.3.20 Set Tag’s specific configuration
SUB-COMMAND = 1FH
4.3.20.1 Configure the LED light’s color
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 00H
DATA[1] = LED light’s color
DATA[1] = LED Color
LED Color = 00H, Red
LED Color = 01H, Green
LED Color = 02H, Orange
LED Color = 03H, LED light Off
For new AT7XX series, big illuminant button(AT705,AT703,AT702, AT70N)
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 00H
