ABLEPick pick-to-light communication protocol
21
18H

Emulating shortage push-button
19H

Switching to stock mode
1AH

Switching to picking mode
1BH

Disabling confirmation push-button
1CH

Enabling confirmation and shortage buttons
1EH

Setting valid digits for counting
1FH

Setting tag’s Multiple configuration
3AH

Setting the device node address
64H

Return from the device
FCH

Get device’s detail information
FCH

Return device’s detail information (same as reset OK )
FAH

Get device’s F/W model information
FAH

Return device’s F/W model information
30H

Display data with the illuminant buttons for AT503-4K
30H

Return message while sending by 30H for AT503-4K
31H

Controlling of the 4 illuminant buttons solely for AT5034K
31H

Return message of 4 illuminant buttons from AT503-4K
32H

AT503-4K auto-demonstrating function
24H

When enable cycle edit bit in sub-command=1F, Data[0] = 0A
FBH

Advanced way to configure device’s node address
F7H

AT400 alarm status control
F7H

AT400 alarm status feedback
Note:
(1)  means sending message from Host to device via TCP/IP controllers.
(2)  means return message from Device to Host via TCP/IP controllers
(3) Symbols to be able to display on device’s 7-segment LED display refer to below “Display
code for Tags”
Display code for Tags
ASCII code
7 segment display
ASCII code
7 segment display
30H
0
6EH
n
31H
1
6FH
o
32H
2
68H
h
33H
3
72H
r
34H
4
75H
u
35H
5
69H
i
36H
6
79H
y
37H
7
74H
t
38H
8
71H
q
39H
9
47H
G
41H
A
53H
S
62H
b
6CH
l
43H
C
4FH
O
64H
d
5BH
[
45H
E
5DH
]
46H
F
50H
P
63H
c
55H
U
48H
H
2DH
-
4CH
L
20H
(space)
4.3 Send Command to Tags (PCTCP/IP controller)
All the different kinds of behaviors on each light module could be controlled from host
