ABLEPick pick-to-light communication protocol
49
4.5.5.1 Selection of AT510M/AT710M’s songs
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 0BH
DATA[1] = 00h~0BH
( 12 songs)
4.5.5.2 Adjust the volume of AT510M/AT710M’s speaker
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 0CH
DATA[1] = 00h~0FH
The volume of sound
16 different levels, 00H(min),
0FH(max)
4.5.6 Protocol for AT503-4K
AT503-4K has 3-digit LED display and 4 lightable buttons. The basic functions are
compatible with the other models. But there are some special functions AT503-4K.
4.5.6.1 Display data with the illuminant buttons
The following describes the sub-command and Data string CCB(communication Control
Block ) to AT503-4K.
CCB Description
CCB LEN(L)= length of CCB
Length of CCB in byte
CCB LEN(H) = 0x00
MESSAGE TYPE = 0x60
0x60: port1 of controller,
Reserved
Reserved
Reserved
SUB-COMMAND
30H
SUB-NODE
0x01~0xFA (address)
or 0xFC (Broadcasting)
Data 0
define buffer index and its specific
light’s status
Data 1
All keys’ status of AT503-4K
Data 2
5
th
digit in LED
Data 3
4
th
digit in LED
Data 4
3
rd
digit in LED
Data 5
2
nd
digit in LED
