ABLEPick pick-to-light communication protocol
50
Data 6
1
st
digit in LED
Dot
Dot position
When sending message to AT503-4K by 30H, then AT503-4K will have 4 buffers to store
the data string. Meantime, each buffer will map to one specific illuminant button, as below:
1
st
buffer -> Red light
2
nd
buffer -> Green light
3
rd
buffer -> Blue light
4
th
buffer -> Yellow light
You have to assign the buffer index you would like to put, in other words, which button you
would like to light on by defining the specific bit value on the data 0, as below:
1) Data [0]: Define the buffer index of sending data and its specific illuminant button’s
status. Bit assignment of Byte is as below.
Bit 0 : LED status
Bit 1 : LED status
Bit 2 : LED status
Bit 3 : Auto retrieve data from buffer and display or not
Bit 4 : Buffer index
Bit 5 : Buffer index
Bit 6 : reserved
Bit 7 : reserved
Bit assignment:
7
6
5
4
3
2
1
0
0 0 0-------- delete this buffer data.
0 0 1-------- Light is ON
0 1 0-------- Light is blinking by 2 second interval
0 1 1-------- Light is blinking by 1 second interval
1 0 0-------- Light is blinking by 0.5 second interval
1 0 1-------- Light is blinking by 0.25 second interval
0-------------------------- By pressing illuminant button to retrieve.
1-------------------------- Auto retrieve data from buffer and display
0 0-------------------------------- assign to 1
st
button
0 1-------------------------------- assign to 2
nd
button
1 0--------------------------------- assign to 3
rd
button
1 1--------------------------------- assign to 4
th
button
PS (1): Bit 3 will configure the sending data is going to be displayed automatically
on LED display (bit 3= 1) or just light on the illuminant button only (bit 3= 0) and
need to press the illuminant button to show up its specific data.
PS (2): When define Bit 3 = 0, when you press the button to display its specific
quantity on LED display. However, you also could press the same button again to
cancel the last job to rollback to standby status.
Example :
Data 0 = 09H  sending data to button 1 by solid on light with auto display.
Data 0 = 19H  sending data to button 2 by solid on light with auto display.
Data 0 = 29H  sending data to button 3 by solid on light with auto display.
Data 0 = 39H  sending data to button 4 by solid on light with auto display.
Data 0 = 01H  sending data to button 1 by solid on light with none-auto display.
Data 0 = 11H  sending data to button 2 by solid on light with none-auto display.
Data 0 = 21H  sending data to button 3 by solid on light with none-auto display.
Data 0 = 31H  sending data to button 4 by solid on light with none-auto display.
