> release up-count first, then confirmation -> return code is 24H
> release confirmation first, then up-count -> return code 14H,
Consider the real application and reasonable design, we only define above
three return codes of confirmation, up-count and down-count buttons for used
implementation..
DATA[0] = 01H
Tag busy. It is the situation that the message queued in tag not be polled back,
and meantime host AP still sending message to it. Then the latter sending
message will be drop off and return one message with sub-command = 64H
and data0 is 01H to inform.
DATA[0] = 02H
This message is only for AT503A, AT502V and AT506-3W-123, when their
buffer is full and the first message has been replaced.
DATA[0] = 03H
The last message in buffer has been displayed on. Just for AT506-3W-123.
DATA[0] = 04H
The return message from the blue function key on the model of AT706-24-3K,
AT706-3K or AT705-RFID.
4.4.11 Return deviceās F/W model string.
Receiving the deviceās F/W model name when sending Sub-command = FAH..
SUB-COMMAND = FAH
Block Length = 8 + 8 = 16Bytes
Data[0~7] : 8-byte model string
Note : The function only can be applied on AT505 V1.2 above and AT7XX
series(excludes AT70C& AT730). However, some models share the same F/W, thus
the return F/W model name will be the same, for example, AT705, AT703, AT702,
AT70N, AT706 share the same F/W version, then the return model name is always
āAT705ā instead.
4.4.12 Return deviceās detail information
Receiving the deviceās detail information when sending Sub-command = FCH..
SUB-COMMAND = FCH
Block Length =13 Bytes
Different models will have different value on the Data bytes
AT5XX
Data[0] : Product ID code
