ABLEPick pick-to-light communication protocol

SUB-COMMAND = 15 H

SUB-NODE = {01H ~ FAH}

0x01~0xFA (address)

or 0xFC (Broadcasting)

4.3.12 Enable the shortage/down-count button

SUB-COMMAND = 16H

CCB LEN (L) = 08H

Data length of this block

CCB LEN (H) = 00H

MESSAGE TYPE = 60H

60H : port 1

Reserved

SUB-COMMAND = 16 H

SUB-NODE = {01H ~ FAH}

0x01~0xFA (address)

or 0xFC (Broadcasting)

4.3.13 Emulating push confirmation button

SUB-COMMAND = 17H

CCB LEN (L) = 08H

Data length of this block

CCB LEN (H) = 00H

MESSAGE TYPE = 60H

60H : port 1

Reserved

SUB-COMMAND = 17 H

SUB-NODE = {01H ~ FAH}

0x01~0xFA (address)

or 0xFC (Broadcasting)

4.3.14 Emulating push shortage/down-count button

SUB-COMMAND = 18H

CCB LEN (L) = 08H

Data length of this block

CCB LEN (H) = 00H

MESSAGE TYPE = 60H

60H : port 1

Reserved

SUB-COMMAND = 18 H

SUB-NODE = {01H ~ FAH}

0x01~0xFA (address)

or 0xFC (Broadcasting)

4.3.15 Switching to stock mode

SUB-COMMAND = 19H

CCB LEN (L) = 08H

Data length of this block

CCB LEN (H) = 00H

MESSAGE TYPE = 60H

60H : port 1

Reserved
